The DHC2000 is an oxy-acetylene torch capable of welding, cutting, brazing, soldering, leading and preheating a variety of ferrous and non-ferrous metals, such as: Mild Steel, Stainless Steel, Aluminum and Cast Iron.
The DHC2000 is the perfect tool for any metal working industry, such as: Fabricating, Metal Art, Automotive Restoration, Farm and Ranch, HVAC and much more. The DHC2000 runs on 4 lbs oxygen and 4 lbs acetylene. Made in the USA with a lifetime warranty!
Key Features:
Versatility - Weld like a TIG | Cut like a PLASMA
The combination of low velocity flame and concentrated heat deliver a new level of welding control and versatility. Since the DHC2000 operates with a flame velocity up to four times lower than a conventional torch, it prevents the molten weld puddle from 'blow out', enabling welding of difficult materials such as Aluminum.
Superior Control
The ergonomic pistol-grip torch body is made from lightweight durable cast aluminum and permits a more natural working position. The oxygen trigger is placed in the grip of the torch handle for cutting actuation at your finger tips.
A unique dual cutting tip configuration separates the oxygen delivery point from the pre-heat source. This design produces narrow, square cuts, that require minimal secondary cleaning. The DHC2000 efficiently cuts mild steel up to one-inch thick.
Fuel Effcient
A unique mixing chamber assures optimum gas mixing for an exceptionally efficient, clean burning flame. That means less money spent refilling your oxygen and acetylene tanks.
Welding
Weld steel, aluminum, cast iron, and stainless among other materials. Applications vary, but generally speaking the welding range is from .010” to .375” thick, or up to 1/2” for small applications.
Cutting
The DHC2000 is ideal for cutting sheet steel greater than .010” thick, up to 1" thick. The low pressure and concentrated flame not only provides for a cleaner cut it also reduces the heat applied to the item being welded, thereby reducing warping of the metal.
Kit Contents
- DHC2000 Pistol-Grip Torch
- Undercutter
- Overcutter
- Guide Rails
- 5 brass Welding Tips
- 1 Copper Cutting Tip
- Check Valves
- Striker
- Wrench
- Tip cleaner
- Instructional DVD
- Manual
- Lockable Gear Box
Specifications
- Gas: Oxygen and Acetylene (Propane tips sold separately)
- Hose Fittings: B-Fitting
- Regulator: Standard or Low Pressure
- Warranty: Lifetime
- Welding: Yes
- Cutting: Yes
- Brazing: Yes
- Soldering: Yes
- Leading: Yes
Industries Served
- Fabrication
- Automotive
- Restoration
- Aviation
- Aerospace
- Agriculture
- Service Truck
- Art
